| 40FT FLATBED TRAILER | |
| Name of Product | 40FT flatbed trailer |
| Dimension(mm) | 12500*2500*1600 |
| Tare Weight(g) | Appr. 7500 KG |
| Pay Load(kg) | 50000 KG |
| Wheelbase(mm) | 1310+1310 |
| Floor(mm) | 4mm pattern plate |
| Cross Beam | 10# channel steel |
| Main Beam(mm) | Height: 520mm |
| Upper Plate thickness:18mm | |
| Middle Plate thickness:10mm | |
| Lower Plate thickness:18mm | |
| Gooseneck reinforcement design | |
| Side Beam | 16# channel steel |
| King Pin | JOST90# |
| Leaf Spring | 10/10/10 pieces(100mm*16mm) |
| Suspensions | Mechanical suspension with reinforcement |
| Landing Gear | FUWA 28T |
| Axle | FUWA 13T*3 |
| Tires | 315/80R22.5*12+1 pieces |
| Wheels | 9.0-22.5*13 |
| Container Twist Locks | 12 sets |
| Relay Valve | WABCO |
| Brake Cylinder | Front 30, Rear 30/30 |
| Spare Wheel Carrier | 2 sets |
| Tool Box | 1 |
| Rope Hook | Cast iron hook and rope tightening device |
| Lamps and lanterns | LED |
| Power outlet | 24V 7-core |
| Color | As required |
